FusionCab 261kWh

A compact and flexible distributed power solution.
FusionCab 261 kWh integrates solar, storage, and diesel in one lightweight unit, ideal for telecom stations, remote sites, and small-scale off-grid facilities.
Designed for trailer transport and plug-and-play deployment, it delivers instant, reliable power with smart monitoring and remote management for effortless energy control.
Availability:
Inquire Add to Basket

facebook sharing button
twitter sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
FusionCab 261kWh
Product Description
The iEZA Series Range-Extended Energy Storage System (FusionCab) integrates lithium iron phosphate (LFP) batteries, a battery management system (BMS), an energy storage converter, fire detection and gas extinguishing systems, a liquid cooling thermal management system, a diesel generator set, and a dispatch control system.

It also features interfaces for photovoltaic (PV) integration and reserved space for a charging module. With rich preset operation modes, comprehensive protection functions, and outstanding control performance, FusionCab is designed to perform reliably even under unstable grid conditions.

It can be widely deployed for peak shaving, dynamic capacity expansion, and off-grid power supply scenarios.


Key Features:

Safety & Reliability


  1. IP54+C3 high protection rating, built to withstand harsh environments.
  2. Tiered BMS protection strategy to ensure cell safety.
  3. Proactive safety warning system for timely alerts and peace of mind.

High Efficiency & Versatility


  1. Seamless transition between grid-tied and off-grid modes.

  2. Adaptable strategies for various scenarios: no grid, weak grid, or solar power.

  3. Maximizes solar consumption and generator efficiency for significant cost reduction.

  4. Capable of 100% three-phase imbalance and 200% short-term overload.

Flexible Deployment


  1. Highly integrated, all-in-one design combining storage, generator, and charging.

  2. Mobile, pre-assembled containerized solution; power availability in as little as one week.

  3. Built-in MPPT solar charge controller.


Intelligence & User-Friendliness


  1. One-touch start/stop operation.
  2. Real-time remote monitoring and cloud-based data storage.
  3. Instant fault alarm notifications.
  4. Automatic generator top-up during non-quiet hours and fuel level management.

  5. Equipped with a bypass mode.




Product Advantages


  • Easier Power Access


In Europe, grid connection and capacity upgrades often involve long waiting times — power plant approvals alone can take 5–7 years due to complex permitting, environmental assessments, and administrative procedures.

FusionCab offers an efficient alternative. As a fully integrated prefabricated solution that combines PV, energy storage, and diesel generation, it bridges the gap between temporary and permanent power infrastructure. Deployment can be completed in as little as one week, enabling true "power-on-arrival" capability.

Moreover, its trailer-mounted design allows for easy transportation and redeployment — like a large-scale mobile power bank — flexibly matching dynamic operational demands and turning power supply into a mobile, reliable asset.

  • Lower Operating Costs


Traditional off-grid systems relying solely on diesel generators suffer from high idle fuel consumption and costly operation.
FusionCab's PV–storage–diesel hybrid coordination intelligently prioritizes solar generation and stores surplus power for later use, maximizing off-peak electricity utilization and cutting overall energy expenses.

When connected to the grid, it also increases PV self-consumption and reduces purchased electricity costs.
In addition, its microgrid architecture enables dynamic capacity expansion, reducing  the need for traditional transformers — lowering upfront investment and capacity-based grid fees, and transforming temporary power supply from passive consumption to active value creation.


  • Higher Intelligence


In case of grid failure, FusionCab switches to off-grid mode within milliseconds, ensuring uninterrupted power for critical operations.

It supports the startup of high inrush loads and intelligently manages diesel generator runtime — operating only in its optimal efficiency range to minimize fuel waste.

Through a cloud-based smart platform, users can remotely monitor operation status, receive safety alerts, and control start/stop functions with one click — achieving unmanned operation while ensuring system safety and reliability.


  • Enhanced Environmental Performance


Tightening carbon emission standards, low-emission zone policies, and noise restrictions have increased the cost of traditional diesel-only solutions.


FusionCab's hybrid microgrid prioritizes clean, locally generated solar power — significantly reducing carbon emissions and noise pollution, while ensuring compliance with environmental regulations and protecting nearby communities.


The system's IP54 + C3 protection rating further enhances durability and energy efficiency, making it a quiet, green, and reliable power solution.


Detailed specifications: iEZA-261KLB-250K



 Item iEZA-261KLB-250K
Battery Parameters Cell Specifications Lithium Iron Phosphate (LFP), 314Ah
Rated Capacity 261.248kWh
Rated Voltage 832V
Operating Voltage Range 702V-949V
Charge/Discharge Rate ≤0.5C
Depth of Discharge 95%DOD
Utility Power Interface Parameters
 Grid Voltage 400V(-10%~15%)
Rated Power 125kW
Rated Current 189A
Rated Frequency 50Hz
Wiring Configuration L1/L2/L3/N/PE (OT terminals)
Power Factor >0.99 (Adjustable 1 Leading ~ 1 Lagging)
THDi <3% (Rated Power)
Load Interface Parameters Rated Capacity 130kVA
Maximum Output Power 250kVA (233kVA @ battery-only mode, bypass excluded)
Overload Duration ≤3s
Rated Output Voltage 400V(-10%~15%)
Rated Output Frequency 50Hz
Wiring Configuration L1/L2/L3/N/PE (OT terminals)
Grid-On/Off Switching Time 0ms (typical)
PV Interface Parameters Maximum String Voltage ≤650VDC
Wiring Configuration PV+/PV- (connected to OT terminals after PV array combiner)
Maximum Input Current ≤100A @ MPPT rated power 50kW
MPPT Rated Power 50kW (100kW optional)
Diesel Generator System Parameters Rated Power 60kW
Fuel Tank Capacity Approx. 150L fuel tank
System Parameters Cooling Method Battery system: intelligent liquid cooling; Others: forced air cooling
Dimensions (W×D×H) 2438*2600*2991mm
Weight <9t
Protection Level (IP Rating) IP54 (battery compartment)
Relative Humidity ≤95%, Non-condensing
Operating Temperature -25℃~50℃ (>45°c Derating)
Maximum Operating Altitude 4000m(>3000m Derating)
Cycle Life 6,000 Cycles @ 70% EOL
Fire Protection Configuration Perfluorohexanone (PACK level)
Optional Accessories Single-phase AC charging (7kW); Wall-mounted AC charging station
